Poly Studio X70

Poly Studio X70 Dual Lens IP Video Bar with Auto Speaker Track 4K 7.3x 120°+70° FOV Cameras (P026)

Poly Studio X70 is a beautifully engineered, premium videoconference solution that combines razor-sharp 4K video with boardroom filling stereo sound for simply the best meeting experience available. With a sleek all-inone plug-and-play design, the Poly Studio X70 eliminates tangled cables and IT headaches while providing robust audio and video. Enjoy native support from your choice of video-as-a-service platforms—no PC needed. Its AI driven video and audio experience enables the Poly Studio X70 to turn any large-room video call into a hassle-free delight.

KEY FEATURES :

• Life-like video with dual cameras each with their own 4K+ sensor.
• Crystal-clear, boardroom-filling audio from two-way stereo speakers, aluminum cone tweeters, and advanced bass ports.
• Pinpoint-accurate speaker tracking and professional-quality group framing from AI-driven camera array.
• Prevent distracting noises and side conversations from interrupting your meetings with NoiseBlockAI and Acoustic Fence technology.

SPECIFICATIONS :

CAMERA

• 2 lenses :
• 120-degree HFOV, 70-degree HFOV
• 140-degree DFOV, 78-degree DFOV
• 2x 20 Megapixel sensors
• 7.3x digital zoom
• UHD 2160p (4K) capture resolution
• Automatic group framing
• Automatic speaker framing
• Additional cameras can be added via USB

AUDIO INPUT

• 1x 3.5 mm

MICROPHONES

• 2x MEMS microphones, plus 2x 2nd order microphones
• Microphone pickup range up to 25 ft
• Optional expansion microphone available (p/n 2200-69631-001)

AUDIO OUTPUT

• 1x 3.5mm
• Two-way Stereo Speakers
• Mid speakers :
• Power Handling (RMS) 20 Watts
• Power Handling (MAX) 30 Watts
• Sensitivity 83 dB
• Tweeter speakers
• Power Handling (RMS) 15 Watts
• Power Handling (MAX) 20 Watts
• Sensitivity 89 dB
• Custom Tuned Bass Ports for rich sound

OTHER INTERFACES

• 2x USB-A (3.0)2
• 1x USB-C3
• Bluetooth® 5.04
• 2x RJ451
• WiFi 802.11a/b/g/n/ac (MIMO) Multi-channel Concurrency

PACKAGE INCLUDES

• Poly Studio X70
• Power Supply
• 2x HDMI cable
• Ethernet Cable
• Wall mount

VIDEO STANDARDS AND PROTOCOLS

• H.264 AVC, H.264 High Profile, H.265

VIDEO INPUT

• 1x HDMI

VIDEO OUT

• 2x HDMI
• Touch display compatible

CONTENT VIDEO RESOLUTION

• Input
• UHD (3840 x 2160)
• FHD (1920 x 1080p)
• WSXGA+ (1680 x 1050)
• UXGA (1600 x 1200)
• SXGA (1280 x 1024)
• WXGA (1280 x 768)
• HD (1280 x 720p)
• XGA (1024 x 768)
• SVGA (800 x 600)
• Output
• UHD (3840 x 2160)
• HD (1920 x 1080)
• WSXGA+ (1680 x 1050)
• SXGA+ (1400 x 1050)
• SXGA (1280 x 1024)
• HD (1280 x 720)
• XGA (1024 x 768)
• Content frame rate
• 5–30 fps (up to 4K resolution at 15 fps in call)

ROOM ANALYTICS

• Room participant counting detection
• Air Quality Sensor1
• CO2 and Volatile Organic Compounds (VOC)

CONTENT SHARING

• Poly content app
• Apple Airplay
• Miracast
• HDMI input
• Whiteboarding

PHYSICAL CHARACTERISTICS

• 840.18 mm/33.1 in (W) x 135.38 mm/5.3 in (H) x 117.33 mm/4.6 in (D)
• 7.05 lbs/3.2 kg

MANAGEABILITY

• Cloud: Poly Lens service

WARRANTY

• 2-year replacement warranty against manufacturing defects
